HyprFab is a modular enclosed line for SMT prototypes. Each station is its own module. Boards move through them on one conveyor.
The lineContact Newmatik
HyprFab line of enclosed modules on one conveyor
The modules

Three stations. One line.

A short line is paste, one place module and reflow. Add place modules between paste and reflow when the board needs them.
HyprFab paste module
Paste
Print solder paste and check the print before the board moves on.
HyprFab place module
Place
Place the components. Add another place module when one is not enough.
HyprFab reflow module
Reflow
Reflow the board in its own enclosed module at the end of the line.
Board flow

The board stays on the conveyor.

From the paste module to reflow, the board moves inside the line.
1

Paste

The board enters the first module. Paste is printed and checked.

2

Place

Components go on the pasted board. A longer line uses more than one place module.

3

Reflow

The board is soldered, then it leaves the line.

Newmatik

Built by the people who assemble boards.

HyprFab is a Newmatik project. Newmatik GmbH assembles SMT boards in Hennweiler and builds the software around that work.
